PCB Classifications By Layers
Multi-Layer PCB
Three or more conductive layers are laminated together with insulating material to form a multi-layer printed circuit board (PCB). The layers are connected by vias. High-performance electronics such as computers, servers, smartphones, and medical devices depend on this intricate PCB construction.
Single-Sided PCB
The most straightforward and economical type of PCB is the single-sided PCB, which only has a conductive copper layer on one side. It is perfect for low-cost, high-volume applications like remote controls, radios, and calculators that use simple PCB designs.
Double-Sided PCB
On the top and bottom sides of a double-sided PCB are conductive copper layers with circuits connected by vias. It is one of the most popular PCB types and is frequently found in consumer electronics, industrial control systems, and power supplies that require compact PCB layouts.
PCB Classifications By Physical Characteristics
Rigid PCB
A solid, non-flexible substrate material, like FR-4 fiberglass, which offers excellent strength and durability for rigid PCB boards. Throughout its lifecycle, it keeps its shape, providing components with a solid base. Commonly used in computer motherboards as a rigid PCB.
Flexible PCB (FPC)
The foundation of a flexible PCB (FPC) is a pliable substrate such as polyimide. This makes it possible for the flexible PCB board to be folded and bent to fit into confined spaces. Ideal for avionics, wearables, and cameras that need flexible PCB solutions.
Rigid-Flex PCB
Combines rigid circuit sections with integrated flexible circuits in a rigid-flex PCB. This hybrid design improves reliability by eliminating the need for connectors and cables. Found in high-end electronics and military applications that use rigid-flex PCB technology.
PCB Classifications By Substrate Material
FR-4 PCB
The substrate is FR-4, a glass-reinforced epoxy laminate for FR-4 PCB boards. This material provides a good mix of cost-effectiveness, mechanical strength, and electrical insulation. It is the most popular PCB material used in mainstream FR-4 PCB production.
Metal Core PCB (MCPCB)
Usually copper or aluminum based, offering superior heat conductivity for metal core PCB (MCPCB) products. Excellent heat dissipation makes it the best option for LED lighting and power converters to prolong component life with MCPCB technology.
High-Frequency PCB
Uses special materials like Teflon or Rogers with low signal loss for high-frequency PCB boards. It is especially made for high-speed signal transmission used in radar, microwave, and high-speed communication devices that require high-frequency PCB solutions.
Get your PCBs Built-Fast
Fast PCB Delivery
PCB Assembly
Fast and reliable SMT & THT PCB assembly service.
Quantity: 1-10,000+pcs.
Quality Grade: IPC3
Lead time: as short as 2 days
AOI, X-ray, SPI, ICT
PCB Layout
Professional PCB design for high-speed and complex circuits.
Layers: Up to 64
Capability: Support 150,000+ PIN
Lead time: 3-10 days
Rigid, Flex, Rigid-Flex, HDI
PCB Manufacturing
Precision PCB fabrication with high reliability and fast delivery.
Layers: 1-32
Quality Grade: Standard IPC3
Lead time: 2-15 days
Flex, Rogers, Alu, etc.
Our Manufacturing Capabilities
Email us at [email protected] or get an instant PCB quote.
| Specification | Capability |
|---|---|
| Minimum Finished Hole Size | 0.15 mm (6 mil) |
| Minimum Annular Ring | 0.10 mm |
| Base Copper Thickness | 1 oz – 3 oz |
| Minimum Trace Width / Spacing | 0.075 mm / 0.075 mm |
| Drill to Copper Clearance | 0.20 mm |
| Layer Count | 2 to 12 Layers |
| Controlled Impedance Tolerance | ±10% |
| Coverlay Opening Tolerance | ±0.05 mm |
| Solder Mask Clearance | 0.06 mm |
Single-Sided PCB
Multilayer PCB
Double-Sided PCB
